Used Wuxi Zhicheng Process Equipment

Phoenix Equipment has a large inventory of used, unused, and reconditioned equipment from Wuxi Zhicheng. Phoenix Equipment offers a wide selection of categories from Wuxi Zhicheng. If you can't find the exact Wuxi Zhicheng equipment you are looking for, contact us and we can help you find it.

Categories
Featured Equipment for Sale
420-sq-ft-wuxi-zhicheng-stainless-steel-shell-tube-heat-exchanger
420 Sq Ft Wuxi Zhicheng Stainless Steel Shell & Tube Heat Exchanger
Stock# 22520 Capacity 420 Sq Ft

Unused approx 420 sq ft TP304L Stainless Steel vertical shell and tube heat exchanger. Manufactured by Wuxi Zhicheng Biochemical Engineering Equipment Co., Ltd. (324) 19.05mm OD x 2000mm L tubes rated 116PSI/FV@220C. SA240 Shell MAWP 175PSI/FV @220C. Lug moutned. Serial #WZA21-27. National Board #154. Built 2021.

1120-sq-ft-wuxi-zhicheng-c276-hastelloy-shell-tube-heat-exchanger
1120 Sq Ft Wuxi Zhicheng C276 Hastelloy Shell & Tube Heat Exchanger
Stock# 22470 Capacity 1120 Sq Ft

Unused 1121 sq. ft. Hastelloy C276 heat exchanger Built by Wuxi Chemical Equipment in 2023. 14.275 Design duty (MMBTU/Hr). Shell Design Rating: 120 psig @ 150 deg. F. (472) 0.75"OD Hastelloy C276 Tubes Design Rating: 95/FV psig @ 300/300 deg. F. Shell mawp 326.8 psig @ 150 deg. F. Tube mawp 95.04 psig @ 300 deg. F. 29" X 144". National Board #550. Serial #WHA2-091-1. Built 2022. Ammonia Stripper Overhead Condenser. Under Nitrogen Purge.

650-sq-ft-wuxi-zhicheng-stainless-steel-shell-tube-heat-exchanger
650 Sq Ft Wuxi Zhicheng Stainless Steel Shell & Tube Heat Exchanger
Stock# 22509 Capacity 650 Sq Ft

Unused 650 sq. ft. 304 Stainless Steel vertical heat exchanger. Mfg. by Wuxi Zhicheng Biochemical Eng. 1.8 Design duty (MMBTU/Hr). Shell Design Rating: 147/FV psig @ 428 deg. F. (336) 19.05mm Tube Design Rating: 174/FV psig @ 428 deg. F.; 20" x 10'0". Oil/Steam heat exchanger. With Expansion Joint. Empty weight 3954 lb. National Board #152. Serial #WZA21-22. Built 2021. Under Nitrogen Purge

234-sq-ft-wuxi-zhicheng-stainless-steel-shell-tube-heat-exchanger
234 Sq Ft Wuxi Zhicheng Stainless Steel Shell & Tube Heat Exchanger
Stock# 22452 Capacity 234 Sq Ft

Unused 234 sq. ft. 316L Stainless Steel horizontal shell and tube heat exchanger. Mfg. by Wuxi Chemical Equipment in 2023. 3.6 Design duty (MMBTU/Hr). Shell Design Rating: 180/FV psig @ 430/300 deg. F. Tube Design Rating: 232/FV psig @ 430/400 deg. F. Shell mawp 186.7/FV psig. Tube mawp 532/FV psig. 5.5" X 108". Serial # WHA22-024-1. National Board #529. Recirculating exchanger. Under Nitrogen Purge.

234-sq-ft-wuxi-zhicheng-stainless-steel-shell-tube-heat-exchanger
234 Sq Ft Wuxi Zhicheng Stainless Steel Shell & Tube Heat Exchanger
Stock# 22453 Capacity 234 Sq Ft

Unused 234 sq. ft. 2205 Duplex SS horizontal shell and tube heat exchanger. Mfg. by Wuxi Chemical Equipment 2023. 3.6 Design duty (MMBTU/Hr). Shell Design Rating: 180/FV psig @ 430/300 deg. F. Tube Design Rating: 232/FV psig @ 430/400 deg. F. Shell mawp 186.7/FV psig. Tube mawp 532/FV psig. 15.5" 108". Serial #WHA22-025-1. National Board #530. Recirculating exchanger. Under Nitrogen Purged.
