Used 14381 gallon 304 Stainless Steel tank. 13'Dia x 19'tall. Flat bottom, dished top. Side manway.
12,000 litre stainless steel vertical tank. Unit measures approximately 2300MM diameter x 3000MM straight side. Has welded flat top and welded cone bottom heads. Unit is mounted on 4 legs. Fitted with side access ladder and safety rail.
Used 11000 gallon stainless steel tank. Dome top, dish bottom. 120" Dia x 168"Straight side. (4) Leg mounted.
Used 10500 gallon stainless steel mix tank. 12' diameter x 13' straight side, slight cone top, flat bottom with sump discharge, bridge mounted Chemineer agitator drive, model 6HHTD-15, 15 HP, 230/460 volt motor, 30 RPM output speed, two tiered 3 blade pitched turbine agitator, 20" top manway, 18" side bottom manway.
Used 10000 Gallon Stainless Steel Storage tank. Cone top and Flat bottom. 11'6" Dia.x 13'10" plus cone top. Last use IPA (Isopropyl Alcohol).
Used 10000 gallon stainless steel tank. 126"D x 192" Straight side. Dish top, flat bottom.
Used 10000 gallon stainless steel tank. 132" D x 144" Straight side. Skirt mounted.
Used 10000 gallon Stainless steel tank. 144" D x144"Straight side. Skirt mounted.
Used 8600 gallon stainless steel tank. 94"D x 24'Straight side. Sloped bottom slight cone top. 3" side bottom outlet. Side manway with cover. Past use Juice Facility.
Used 8600-gallon stainless steel bulk storage tank. 94" dia X 24' straight side, sloped bottom, Fully insulated. 3" dia side bottom outlet. Previously used at juice production.
Used approximately 8000 gallon vertical 304 stainless steel tank. 10'diameter X 14' high straight side. Slight cone top, flat bottom. Top fittings: (3) 8", (1) 6", (2) 2", and (1) 4". Has (3) 1.5" side pad style inlets, (1) 6" side pad style outlet, (1) 8" side bottom pad style outlet, and (1) 4" side bottom outlet. Has internal coil. Covered with 3" insulation and sheathing.
Used 8000 gallon stainless steel tank. 104"D x 210"Straight side. Flat top, cone bottom. Leg mounted
Used 8000 gallon stainless steel mix tank. 104"D x 198" Straight side. Top bridge mounted agitator. Flat top, cone bottom. (6) leg mounted.
Used 6400 gallon stainless steel tank. Top center mounted agitation. Dome top, dish bottom. 108"D x 140" Straight Side. Skirt mounted.
Used 6391 gallon 304 stainless steel vertical mixing tank. Internal coils, insulated. Top mounted agitator, 2" 304 stainless steel coil. Atmospheric pressure. (4) internal sidewall baffles. Flat top and dished bottom. On lug supports.
Used 6000 gallon stainless steel tank. Flat top, dish bottom. Dims 112" Dia x 156" Straight side. (4) Leg mounted.
Used 5800 gallon Stainless Steel mixing tank. Top entering 4-blade agitator 10hp motor. Internal baffles. (4) Leg mounted. Dome top, dish bottom. Top manway. Dimensions: 13'H X 105"D
Used 5600 gallon stainless steel tank. Dome top, dish bottom. 108"D x 108"Straight side. Skirt mounted.
Used 5000 gallon Stainless Steel vertical tank. Side entering manway. (4) leg mounted.
Used 4800 gallon stainless steel tank. Dome top, disbottom. (4) leg mounted.
Used 4750 Gallon, 304 Stainless Steel, Vertical Tank. 84" Diameter x 200" straight side, flat top, sloped bottom. Internal sidewall ladder. Openings top 1-1/2" tri-clamp, (2) 2" NPT, 3-1/2" threaded, 20" man way with cover. 2-1/2" Off center bottom outlet. Mounted on 4 carbon steel legs with skirt. No manufacturers tag. Previous use: water storage for brewery.
Used 4500 gallon stainless stell mix tank. 7'6"ID x 14' Straight-side (OAH 18'). Flat top, slight cone bottom with 2” diameter center bottom discharge. Top head includes MixMor Model T0B-2-N20 bridge mounted, top entering agitator drive and a partial hinged lid. Agitation includes a stainless steel shaft and two 4-blade pitched turbine bolted paddles, driven by 2 HP, 208-230/460V, 1725 RPM, 3/60Hz motor thru Falk gear reducer. (4) Leg mounted.
Used 4300 gallon stainless steel tank. Dims 102"D x 108"Straight side. Flat top, cone bottom. Leg mounted.
Used 4200 gallon stainless steel tank. Dims 102"D x 104" Straight side. Flat top, cone bottom. Leg mounted.
Used 4000 gallon stainless steel tank. 108"D x 105"Straight side. Flat top, cone bottom. (6) Leg mounted.
Used 4000 gallon stainless steel mix tank. 116"D x 86"Straight side. Top bridge mounted agitator. Flat top, dish bottom. (3) Leg mounted.
Used 4000 gallon stainless steel mix tank. 108"D x 110" Straight side. Top mounted agitator. Flat top, cone bottom. (6) leg mounted.
Used 3900 gallon 304 Stainless Steel Vertical Mix tank with internal coil. 304SS coil, insulated. Shell rated ATM @475F. Top Mounted Agitation, (4) Internal Sidewall Baffles, Flat Flanged Top & Dished Bottom.
Used 3300 gallon stainless steel tank. Dims: 90"D x 96" Straight side. Dish top and bottom. Top manway. Skirt mounted.
Used 2750 gallon stainless Steel tank. 7'6"ID x 8'Straight-side (OAH 10'4"). Flat top with (2) Partial hinged lids and Cone bottom with 2" Center Bottom outlet. 2HP side entering agitator. (4) Leg mounted.
Used approximately 2500 gallon vertical 304 stainless steel tank. Approximately 84" diameter X 9' 4" straight side. Open top. Flat bottom. Center bottom outlet.
Used 2250 gallon Stainless Steel Mix tank. 6’ID x 8’3” straight side (16'OAH). Dish top and dish bottom. 15” diameter flange connection to 2” diameter pipe discharge. Top-entering, flange-mounted agitation with stainless steel shaft and two 3-blade stainless steel props, driven by 3 HP, 208-220/440V, 1760 RPM, 3/60Hz motor. 18” diameter top-entering manway with six top inlets two 4”, two 2” & two 1 1/2”. Lug Mounted within mild steel frame with (4) legs and footpads.
Used 2000 Gallon Stainless Steel Agitated Tank. 6’4” diameter x 8’ straight side (10"9' OAH) with a slight cone top and slight cone bottom, 2 1/2” diameter center bottom discharge with a 90-degree elbow. Side-entering agitator connected to flange connection. Agitator driven by 2 HP motor. Top head includes 18” diameter manway and two 2-1/2” diameter openings. Straight side includes side ladder with step platform. (5) Leg mounted.
Used 2000 gallon Stainless Steel agitated tank. 6'D x 10' Straight side (12' OAH). Cone top, sloped bottom with 2" side discharge with manual valve and sample port with valve. 2HP Side entering agitator. 18" Top manway and (2) 2" openings. (6) Leg mounted.
Used 1200 gallon vertical stainless steel vessel. 304 stainless steel. Dished heads. On leg supports.
Used 1000 gallon stainless steel mix tank. 60"D x 80"straight side. Top, bridge mounted agitator. flat top and dish bottom. (3) Leg mounted.
Used 1000 gallon Stainless Steel tank. Top mounted agitator. Dims 60"D x 90" straight side. Dish top and bottom. (4) leg mounted.
Used 1000 gallon Stainless Steel mix tank. 64"D x 72" straight side. Angled top entering agitator. Flat top, cone bottom. Top Manway. (6) Leg mounted.
Used 900 gallon stainless steel mix tank. 46"ID x 10' s/s (11'7" OAH). flat top and dish bottom with 3" CBO. MixMor Model T0-1.5 top-entering, bridge-mounted agitation with stainless steel shaft and three 4-blade stainless steel bolted pitched-turbine blades along common stainless steel shaft, driven by 1.5 HP, 230/460V, 1740 RPM, 3/60Hz motor. (4) Leg mounted.
Used 850 gallon open top jacketed stainless steel sanitary mixing tank, dimple jacket body with independent jackets on wall and bottom, side wall is shrouded and insulated and had been in house pressure tested to 20 psi, bottom jacket is open and exposed from previous repair and testing shows multiple leaks which are repairable, 66" id x 58" deep with flat sloped bottom to 2" discharge with npt connection (can be changed to food service) with 12" floor clearance, central bridge with 1. 5 HP gear motor 208-220/440/3 phase voltage by master @ 18 rpm driving paddle agitator with retreating curves (as modified for former usage), dual hinged covers. Formerly used in food ingredients.
Used 770 gallon 304 Stainless Steel tank. Flat top, dish bottom. Lug mounted. Agitator. Past use Recovered Slurry tank
